DGCON CONVERTING MACHINE FOR DIGITAL PRINTED LABEL

LABEL CONVERTING
DGCON DIGITAL PRINTED LABEL CONVERTING MACHINE
ORTHOTEC 30 years experience dedicates in printing technology to achieve high speed & Multifunctional converting machine with sturdy & easy operation mechanical construction and precise printing & converting accuracy.

SPECIAL FEATURES:
Exclusive Semi-rotary Motion By Liner Ball Screw Mechanical Design:
Gives a consistent registration after longer running.

ORTHOTEC Semi-rotary Technology and 20 Years Experience:
Ensure excellent registration and low wastage during STOP/ START.
Auto-Register Mark Correction:
All Semi-rotary or Flat-bed Station have scanner for registration correction

No Chain and Belts Transmissions Are Used at Main Axis:
Driven directly by gears and servo motors to achieve precise registration and long duration.
DGCON DIGITAL PRINTED LABEL CONVERTING MACHINE
MODEL NAME
DGCON330
PAPER WEB WIDTH
330MM
PAPER FORWARD
300MM
MAX. MECHANICAL SPEED
12000RPH
MAX. PRINTING AREA
MAX. 300MM(W) X 300MM(L)
STANDARD FUNCTIONS
Unwinder with Webguider, Semi-rotary Rotary Die-cut Station, Rewinder with Two Shafts Slitter.
OPTIONAL FUNCTIONS
Cold-stamping Unit, Flexo Varnishing Unit, Screen Printing Station, Flat-bed Hot-stamp Station,  K&B Gap Master Magnetic Rotary Die-Cut Unit , Glue side & Back Side Printing Station, Lamination station with scanner, Flat-bed Embossing Station, Magnetic Rotary Die-cut Station,
NOTES
  1. Real working speed depend from materials, designs, repeat length, skills of operator and etc..
  2. All specifications are subject to change without notice. Please check with your supplier for exact offer.
  3. Specification and features vary by models, and all images might be illustrative for reference only.
*The above specification is for reference only,  the operational speed and width depends on printing length, operator skill, design, job, and many other factors.
*The specification, picture, functions of machine might change without notice. Kindly check with your distributor or ORTHOTEC
